Frequency range (±3dB)                  45Hz-20KHz

Rated impedance                             4Ω

Sensitivity (@2.83V/1m)                  96dB / Peak value: 115dB

Recommended matching power      160W~320W

Recommended power                      200W

Rated power (continuous/peak)       160W/400W

Tweeter                                            1 inch compressed horn tweeter

Woofer                                              Four 6.5 inches black magnesium alloy cone, rubber edge

Product net weight                            15kg/piece

Product size (WxDxH)                      1070x230x120 mm

Opening size (WxDxH)                     1045x200 mm, the depth from the wall to the inside is ≥110 mm

Wiring terminal                                  Single wire partial tone

Place of production                           China
