Features:


1. Ultra-thin closed box.


2. Double professional cinema-level speaker units.


3. The double horn sound wave diffusion design makes the dynamic more broad.


4. AVANCE original high-power belt-type dual tweeters, the high frequency is more transparent and bright.


5. AVANCE original double bullet midrange unit, the sound image positioning is more accurate.


6, AVANCE original damping coating double bass unit, low frequency is more powerful and shocking.


7. The installation method of hanging on the wall or hidden in the wall.

Frequency range (±3dB)                     50Hz-20KHz

Rated impedance                                8Ω

Sensitivity (@2.83V/1m)                     100dB / Peak:120dB

Recommended matching power         70W~250W

Recommended power                         85W

Rated power (continuous/peak)          70W/350W

Tweeter                                               2×1" copper tape tweeter

Midrange                                           2×2.5" cloth dome alto

Woofer                                                2×8" black paper cone

Product net weight                              17.5kg/piece

Product size (WxDxH)                        630x165x490 mm

Cut-out size (WxDxH)                         650x175x510 mm

Wiring terminal                                   Single wire partial tone

Place of production                            China
