IW-313
In order for enthusiasts to be more satisfied with home theater, AVANCE has developed a new theater product IW-313. It uses a professional cinema-level speaker unit and a horn sound wave diffusion design, which makes the dynamic more broad.
characteristic
specifications
pictures
explain
video

Features:


1. Ultra-thin closed box.


2. Professional theater-level speaker unit.


3. The horn sound wave diffusion design makes the dynamic more broad.


4. Crown's original high-power belt tweeter, the high frequency is more transparent and bright.


5. Crown's original bullet midrange unit, the sound image positioning is more accurate.


6. Crown's original damping coating woofer, the low frequency is more powerful and shocking.


7. The installation method of hanging on the wall or hidden in the wall.

Frequency range (±3dB)                   50Hz--25KHz

Nominal impedance                           8Ω

Sensitivity (@2.83V/1m)                    95dB / Peak:105dB

Recommended matching power        30W~120W

Recommended power                       40W

Rated power (continuous/peak)        30W/200W

Tweeter                                             1×1" copper tape tweeter

Alto unit                                             1×2.5" cloth dome alto

Woofer                                              1×6.5" black paper cone

Product net weight                            6.5kg/piece

Product gross weight                        7.5kg/box

Product size (WxDxH)                      445x165x250 mm

Hole size (WxDxH)                           465x175x270 mm

Wiring terminal                                 Single wire partial tone

Place of production                          China
