CD-10
Looking at the impression of this AVANCE CD-10, its high-frequency part is not as prominent as the general modern models, it can be said to be soft; its lines are more detailed, and its mid-frequency has a good gloss. With the sense of substance, but not
Features
Specification
Description

Features:

1. Adopt accurate PC disc reading system

2. Adopt CD special high-precision movement, good stability and strong reading ability

3. Support the latest specifications to read true 32bit/192kHz decoding

4. High-standard digital audio signal

5. Support balanced RCA ultra-high output

6. Fever-level multi-layer filter circuit, effectively remove the digital smell in the sound source signal, perfectly restore the sound source signal output.

7. The circuit uses audiophile-grade non-polarity (MKP) capacitors and audiophile-grade audio special electrolysis for filtering.


















CD-10

Product parameters:

Output level 2.0V

Frequency response 5Hz-20KHz

Signal to noise ratio 110dB

Dynamic range 120dB

Channel separation 110dB

Digital output S/PDIF 0.5VP-P 75Ω

         BNC 0.5VP-P 50Ω

         AES 0.5VP-P 110Ω

Power supply voltage ~220V±5% 50Hz

Power consumption 25W

Net weight 21Kg

Gross weight 24Kg

Product size (WxDxH) 440x433x155mm

Packing size (WxDxH) 522x521x226mm

Packing form 1pc/carton

Place of Origin China
