technical parameter
Output power front ≥50W+50W PMPO(4Ω)
Front ≥25W+25W PMS(4Ω)
Center ≥50W PMPO(4Ω)
Center set ≥25W PMS (4Ω)
Surround ≥50W+50W PMPO(4Ω)
Surround ≥25W+25W PMS(4Ω)
Subwoofer ≥120W PMPO (4Ω)
Subwoofer ≥80W RMS (4Ω)
Harmonic distortion ≤0.5%
Frequency Range
Main channel 20Hz~30KHz (+1/-3dB)
Center channel 20Hz~30KHz (+1/-3dB)
Surround channel 20Hz~30KHz (+1/-3dB)
Subwoofer channel 15Hz (-10dB) ~ 170Hz (-10dB)
Separation >40dB
Signal-to-noise ratio front >81dB (A weighting)
Center set >81dB (A weighting)
Surround >81dB (A weighting)
Subwoofer >81dB (A weighting)
Input sensitivity
/Impedance line input ≤250mV/47KΩ
Microphone input ≤30mV/1KΩ
Power input ~220V 50Hz
Power consumption 300W
Dimensions (WXDXH) 430X365X85mm
Weight 6.5kg
