technical parameter
Disc type DVD, MP4, Super VCD/VCD/DVCD, MP3, CD, CD-R/CD-RW
Output Interface
Audio 2-channel independent output, fiber output, coaxial output
Video composite signal (AV) output
S terminal output Y, Pb/Cb, Pr/Cr component video output VGA
Video characteristics Video amplitude: 1.0 Vp_p (75Ω) load
Y output amplitude 1.0 Vp_p (75Ω) load
C output amplitude 0.286Vp_p/NTSC; 0.3Vp_p/PAL (75Ω load)
Frequency characteristics 20~20KHz(+1db)
Audio features
Output power Front: ≥30W+30W PMPO(4Ω)
Front ≥15W+15W RMS(4Ω)
Subwoofer ≥50W PMPO (4Ω)
Subwoofer ≥25W RMS(4Ω)
Harmonic distortion <0.5%
Frequency response Main channel 100Hz~20KHz(+1/-3dB)
Subwoofer channel 15Hz(-10dB)~130Hz(-10dB)
Separation> 40dB
Signal to noise ratio Front> 90dB (A-weighted) Subwoofer> 90dB (A-weighted)
Power supply voltage ~220V 50Hz
Power consumption 100W
Operating temperature 15~75% (no water drop condensation)
