Exquisite aluminum alloy shell, effectively prevent external magnetic interference
·Through mode output
Optimized smart circuit design, greatly improved the analytical power
The current has no negative feedback amplifier circuit, and the distortion is extremely low
·High capacity, low leakage magnetic transformer
·Six-channel high-power independent output
·Built-in multiple surround sound decoders
·AM/FM tuning
·Multifunctional personalized automatic search remote control
·Sweet sound and good control
technical parameter
RMS output power 8Ω 1%THD main channel 100WX2
8Ω 1%THD secondary channel 80WX4
Frequency response
EXT6.1 10Hz~50KHz
Through 10Hz~50KHz
Decoding 20Hz~20KHz
Subwoofer 10Hz~100KHz
Total harmonic distortion ≤0.2%
Signal to noise ratio (through) ≥85dB
Separation
Dual channel, Dolby Digital and dts status ≥50dB
Dolby Pro Logic ≥40dB
Input sensitivity
Analog input 180MV/47KΩ
Microphone 20MV/600Ω
Maximum input level
Analog audio ≥3V rms
Video ≥1.5V p-p
Microphone ≥0.3V rms
Tone adjustment range
Main channel Treble 10KHz±10dB
Bass 100Hz±10dB
Karaoke treble 10KHz±10dB
Bass 100Hz±10dB
Radio tuning
Receiving frequency range:
FM 87.00MHz~108.00MHz
AM 522KHz~1611KHz
S/N ratio:
FM 70dB
AM 50dB
Sensitivity:
FM (50dB noise limit) 16dB μ
AM (26dB noise limit) 60dB μ/m
Skyline:
FM 75Ω unbalanced antenna
AM frame antenna
Weight 13.5kg
Dimensions (WxHxD) 430x425x170mm
