technical parameter
Is it active?
The main technical parameters of the power amplifier:
Input sensitivity 130mV/22KΩ
Output power 80W (100kHz, 4Ω)
Frequency response range 35HZ-120Hz
Harmonic distortion 0.5%
Signal to noise ratio 90dB
The main technical parameters of the speaker
Impedance 4Ω
Matching power 40-200W
Frequency response 35Hz-120Hz
Sensitivity 90dB
Woofer 1X10 inch
General specifications:
Power supply ~220V±5%, 50Hz
Power supply power ≤200W (rated condition)
Dimensions (width X depth X height) 460X190X500mm
Weight 16.5Kg
