technical parameter:
Output Power
Main sound channel 50-300W
Sub channel 48/20000Hz
Input sensitivity 88dB
Total harmonic distortion 7" Scan Speak/Avance
Machine external dimensions 440 (W) X480 (D) X182 (H)
Weight 25KG
Disc type DVD, MP4, Super VCD/VCD/DVCD, MP3, CD, CD-R/CD-RW
Output Interface
Audio 2-channel independent output, fiber output, coaxial output
Video composite signal (AV) output
S terminal output Y, Pb/Cb, Pr/Cr component video output VGA
Video characteristics Video amplitude: 1.0 Vp_p (75Ω) load
Y output amplitude 1.0 Vp_p (75Ω) load
C output amplitude 0.286Vp_p/NTSC; 0.3Vp_p/PAL (75Ω load)
Frequency characteristics 20～20KHz(+1db)
Audio features
Output power Front: ≥30W+30W PMPO(4Ω)
Front ≥15W+15W RMS(4Ω)
Subwoofer ≥50W PMPO (4Ω)
Harmonic distortion ＜0.5%
Frequency response Main channel: 100Hz～20KHz(+1/-3dB)
Subwoofer channel 15Hz(-10dB)～130Hz(-10dB)
Separation> 40dB
Signal-to-noise ratio pre-＞90dB (A-weighted)
Subwoofer ＞90dB (A-weighted)
Power supply voltage ～220V 50Hz
Power consumption 100W
Operating temperature 15～75% (no water drop condensation)
